製品
OMBX-2SFN コンピューター制御のワイヤーストリッパー

Model

OMBX-10S

Size

400×400×280

Weight

35Kg

Working power

AC220V 50Hz/60Hz 450W (special voltage can be customized)

Operating method

Pushbutton + 192 x 64 dot matrix screen

Size range

AWG7#~AWG28# (depending on wire material and construction) up to BV10mm2

Cutting length

0.1~99999.9mm

Stripping length

Front end: 0~30  Back end:0-100(more than 30 need to be half stripped)

Cutting tolerance

±(0.2+0.003×L)mm (L equals length)

Blade material

Tungsten steel or high speed steel

Working speed

3500 strips/hour (100mm long, 3mm full peel front and back even)

Drive type

2 phase hybrid stepper motor

Wires can be processed

PVC, VSF, Teflon, glass fibre wire, etc.

Important notes

If in doubt about this parameter, please provide a sample of the harness for testing
